The expansion slot of a computer
Expansion slots for PC s come in two basic sizes: half- and full-size. Half-size slots are also called 8- bit slots because they can transfer 8 bits at a time. Full-size slots are sometimes called bit slots. In addition, modern PCs include PCI slots for expansion boards that connect directly to the PCI bus. In computers, a slot, or expansion slot, is an engineered technique for adding capability to a computer in the form of connection pinholes (typically, in the range of 16 to 64 closely-spaced holes) and a place to fit an expansion card containing the circuitry that provides some specialized capability, such as video acceleration, sound, or disk. Expansion slot definition is - a socket on the motherboard of a computer into which an expansion card may be inserted. a socket on the motherboard of a computer into which an expansion card may .
Clicking on any of the links below provide you with additional details. It provides an installation point for a hardware expansion card to be connected. How do I remove an expansion card in my computer? Alternatively known as a bus slot or expansion port , an expansion slot is a connection or port inside a computer on the motherboard or riser card. Installing a computer sound card.
Alternatively referred to as an add-on card , expansion board , internal card , interface adapter , or card , an expansion card is a PCB that fits into an expansion slot on a desktop computer. An expansion card is used to give a computer additional capabilities, such as enhanced video performance via a graphics card.
Expansion cards can sometimes be called daughterboards. However, it is more appropriate to refer to them as expansion cards or one of the terms mentioned earlier.
The above devices are available as expansion cards and can also be onboard the motherboard. Below is a graphic illustration of an ISA Modem expansion card click the picture to get a descriptive overview.
As seen in the picture, an expansion card has two main parts, the gold plated connector that connects to a motherboard expansion slot and the connector plate. The back metal plate often has connections that allow an outside device to communicate with the card and computer. In this example, the modem has two RJ jacks that allow it to communicate over a phone line.
Alternatively known as a bus slot or expansion port , an expansion slot is a connection or port inside a computer on the motherboard or riser card. It provides an installation point for a hardware expansion card to be connected. For example, if you wanted to install a new video card in the computer, you'd purchase a video expansion card and install that card into the compatible expansion slot. Below is a listing of expansion slots commonly found in a computer and the devices associated with those slots.
Clicking on any of the links below provide you with additional details. Many of the above expansion card slots are obsolete. In the picture below is an example of what expansion slots may look like on a motherboard.
Every computer motherboard is different, to determine how many expansion slots are on your computer motherboard identify the manufacturer and model of the motherboard. Once you've identified the model of motherboard, you can find complete information about the motherboard in its manual.
Adding additional expansion slots for older motherboards could be accomplished by using a riser board , which would add several ISA or PCI slots. Today, riser boards are rarely used with motherboards, as there is limited need for additional expansion slots with modern motherboards.
As mentioned above, every motherboard model is unique, so to determine the type of expansion slots on the motherboard, consult the board's specifications and owner's manual.
